0x0B. SSH

Background Context
dance
Resources
Learning Objectives

At the end of this project, you are expected to be able to explain to anyone, without the help of Google:

General

  • What is a server

  • Where servers usually live

  • What is SSH

  • How to create an SSH RSA key pair

  • The advantage of using #!/usr/bin/env bash instead of /bin/bash

Requirements

  • Allowed editors: vi, vim, emacs

  • All your files will be interpreted on Ubuntu 20.04 LTS

  • All your files should end with a new line

  • A README.md file, at the root of the folder of the project, is mandatory

  • All your Bash script files must be executable

  • The first line of all your Bash scripts should be exactly #!/usr/bin/env bash

  • The second line of all your Bash scripts should be a comment explaining what is the script doing

Tasks

0. Use a private key

Write a Bash script that uses ssh to connect to your server using the private key ~/.ssh/school with the user ubuntu.

  • Requirements:

    • Only use ssh single-character flags

    • You cannot use -l

    • You do not need to handle the case of private key protected by a passphrase

sylvain@ubuntu$ ./0-use_a_private_key ubuntu@server01:~$ exit Connection to 8.8.8.8 closed. sylvain@ubuntu$
GitHub Repository:
alx-system_engineering-devops
Directory:
0x0B-ssh
File:
0-use_a_private_key

1. Create an SSH key pair

Write a Bash script that creates an RSA key pair.

  • Requirements:

    • Name of the created private key must be school

    • Number of bits in the created key to be created 4096

    • The created key must be protected by the paraphrase betty

Example:
sylvain@ubuntu$ ls 1-create_ssh_key_pair sylvain@ubuntu$ ./1-create_ssh_key_pair Generating public/private rsa key pair. Your identification has been saved in school. Your public key has been saved in school.pub. The key fingerprint is: 5d:a8:c1:f5:98:b6:e5:c0:9b:ee:02:c4:d4:01:f3:ba vagrant@ubuntu The key's randomart image is: +--[ RSA 4096]----+ | oo... | | .+.o = | | o + B + | | o. = O | | .. S = . | | .. . | | E. . | | .. | | .. | +-----------------+ sylvain@ubuntu$ ls 1-create_ssh_key_pair school school.pub sylvain@ubuntu$
GitHub Repository:
alx-system_engineering-devops
Directory:
0x0B-ssh
File:
1-create_ssh_key_pair

2. Client configuration file

Your machine has an SSH configuration file for the local SSH client, let’s configure it to our needs so that you can connect to a server without typing a password. Share your SSH client configuration in your answer file.

  • Requirements:

    • Your SSH client configuration must be configured to use the private key ~/.ssh/school

    • Your SSH client configuration must be configured to refuse to authenticate using a password

Example:
sylvain@ubuntu$ ssh -v ubuntu@98.98.98.98 OpenSSH_6.6.1, OpenSSL 1.0.1f 6 Jan 2014 debug1: Reading configuration data /etc/ssh/ssh_config debug1: /etc/ssh/ssh_config line 47: Applying options for * debug1: Connecting to 98.98.98.98 port 22. debug1: Connection established. debug1: identity file /home/sylvain/.ssh/school type -1 debug1: identity file /home/sylvain/.ssh/school-cert type -1 debug1: Enabling compatibility mode for protocol 2.0 debug1: Local version string SSH-2.0-OpenSSH_8.1 debug1:Remote protocol version 2.0, remote software version OpenSSH_7.6p1 Ubuntu-4ubuntu0.5 debug1: match: OpenSSH_7.6p1 Ubuntu-4ubuntu2.1 pat OpenSSH* compat 0x04000000 debug1: SSH2_MSG_KEXINIT sent debug1: SSH2_MSG_KEXINIT received debug1: kex: server->client aes128-ctr hmac-sha1-etm@openssh.com none debug1: kex: client->server aes128-ctr hmac-sha1-etm@openssh.com none debug1: sending SSH2_MSG_KEX_ECDH_INIT debug1: expecting SSH2_MSG_KEX_ECDH_REPLY debug1: Server host key: ECDSA bd:03:f8:6a:12:28:d6:17:85:c1:b6:91:f1:da:0f:37 debug1: Host '98.98.98.98' is known and matches the ECDSA host key. debug1: Found key in /home/sylvain/.ssh/known_hosts:1 debug1: ssh_ecdsa_verify: signature correct debug1: SSH2_MSG_NEWKEYS sent debug1: expecting SSH2_MSG_NEWKEYS debug1: SSH2_MSG_NEWKEYS received debug1: SSH2_MSG_SERVICE_REQUEST sent debug1: SSH2_MSG_SERVICE_ACCEPT received debug1: Authentications that can continue: publickey,password debug1: Next authentication method: publickey debug1: Trying private key: /home/sylvain/.ssh/school debug1: key_parse_private2: missing begin marker debug1: read PEM private key done: type RSA debug1: Authentication succeeded (publickey). Authenticated to 98.98.98.98 ([98.98.98.98]:22). debug1: channel 0: new [client-session] debug1: Requesting no-more-sessions@openssh.com debug1: Entering interactive session. debug1: client_input_global_request: rtype hostkeys-00@openssh.com want_reply 0 debug1: Sending environment. debug1: Sending env LANG = en_US.UTF-8 ubuntu@magic-server:~$

In the example above, we can see that ssh tries to authenticate using school and does not try to authenticate using a password. You can replace 98.98.98.98 by the IP of your server for testing purposes.

GitHub Repository:
alx-system_engineering-devops
Directory:
0x0B-ssh
File:
2-ssh_config

3. Client configuration file (w/ Puppet)

Let’s practice using Puppet to make changes to our configuration file. Just as in the previous configuration file task, we’d like you to set up your client SSH configuration file so that you can connect to a server without typing a password.

  • Requirements:

    • Your SSH client configuration must be configured to use the private key ~/.ssh/school

    • Your SSH client configuration must be configured to refuse to authenticate using a password

Example:
vagrant@ubuntu:~$ sudo puppet apply 100-puppet_ssh_config.pp Notice: Compiled catalog for ubuntu-xenial in environment production in 0.11 seconds Notice: /Stage[main]/Main/File_line[Turn off passwd auth]/ensure: created Notice: /Stage[main]/Main/File_line[Declare identity file]/ensure: created Notice: Finished catalog run in 0.03 seconds vagrant@ubuntu:~$
GitHub Repository:
alx-system_engineering-devops
Directory:
0x0B-ssh
File:
100-puppet_ssh_config.pp
Last modified: 05 September 2024
