0x0A. Configuration management

When I was working for SlideShare, I worked on an auto-remediation tool called Skynet that monitored, scaled and fixed Cloud infrastructure. I was using a parallel job-execution system called MCollective that allowed me to execute commands to one or multiple servers at the same time. I could apply an action to a selected set of servers by applying a filter such as the server’s hostname or any other metadata we had (server type, server environment…). At some point, a bug was present in my code that sent nil to the filter method.

There were 2 pieces of bad news:

1. When MCollective receives nil as an argument for its filter method, it takes this to mean ‘all servers’

2. The action I sent was to terminate the selected servers

I started the parallel job-execution and after some time, I realized that it was taking longer than expected. Looking at logs I realized that I was shutting down SlideShare’s entire document conversion environment. Actually, 75% of all our conversion infrastructure servers had been shut down, resulting in users not able to convert their PDFs, powerpoints, and videos… Pretty bad!

Thanks to Puppet, we were able to restore our infrastructure to normal operation in under 1H, pretty impressive. Imagine if we had to do everything manually: launching the servers, configuring and linking them, importing application code, starting every process, and obviously, fixing all the bugs (you should know by now that complicated infrastructure always goes sideways)…

Obviously writing Puppet code for your infrastructure requires an investment of time and energy, but in the long term, it is for sure a must-have.

^_^

Resources

General

• All your files will be interpreted on Ubuntu 20.04 LTS

• All your files should end with a new line

• A README.md file at the root of the folder of the project is mandatory

• Your Puppet manifests must pass puppet-lint version 2.1.1 without any errors

• Your Puppet manifests must run without error

• Your Puppet manifests first line must be a comment explaining what the Puppet manifest is about

• Your Puppet manifests files must end with the extension .pp

0. Create a file

Using Puppet, create a file in /tmp

• Requirements

  • File path is /tmp/school

  • File permission is 0744

  • File owner is www-data

  • File contains I love Puppet

Example:

root@6712bef7a528:~# puppet-lint --version puppet-lint 2.5.2 root@6712bef7a528:~# puppet-lint 0-create_a_file.pp root@6712bef7a528:~# root@6712bef7a528:~# puppet apply 0-create_a_file.pp Notice: Compiled catalog for 6712bef7a528.ec2.internal in environment production in 0.04 seconds Notice: /Stage[main]/Main/File[school]/ensure: defined content as '{md5}f1b70c2a42a98d82224986a612400db9' Notice: Finished catalog run in 0.03 seconds root@6712bef7a528:~# root@6712bef7a528:~# ls -l /tmp/school -rwxr--r-- 1 www-data www-data 13 Mar 19 23:12 /tmp/school root@6712bef7a528:~# cat /tmp/school I love Puppetroot@6712bef7a528:~#

GitHub repository:

alx-system_engineering-devops

Directory:

0x0A-configuration_management

File:

0-create_a_file.pp

1. Install a package

Using Puppet, install flask from pip3.

• Requirements:

  • Install flask

  • Version must be 2.1.0

Example:

root@9665f0a47391:/# puppet apply 1-install_a_package.pp Notice: Compiled catalog for 9665f0a47391 in environment production in 0.14 seconds Notice: /Stage[main]/Main/Package[Flask]/ensure: created Notice: Applied catalog in 0.20 seconds root@9665f0a47391:/# flask --version Python 3.8.10 Flask 2.1.0 Werkzeug 2.1.1

GitHub repository:

alx-system_engineering-devops

Directory:

0x0A-configuration_management

File:

1-install_a_package.pp

2. Execute a command

Using Puppet, create a manifest that kills a process named killmenow.

• Requirements:

  • Must use the exec Puppet resource

  • Must use pkill

Terminal #0 - starting my process:

root@d391259bf577:/# cat killmenow #!/bin/bash while [[ true ]] do sleep 2 done root@d391259bf577:/# ./killmenow

Terminal #1 - executing my manifest

root@d391259bf577:/# puppet apply 2-execute_a_command.pp Notice: Compiled catalog for d391259bf577.hsd1.ca.comcast.net in environment production in 0.01 seconds Notice: /Stage[main]/Main/Exec[killmenow]/returns: executed successfully Notice: Finished catalog run in 0.10 seconds root@d391259bf577:/#

Terminal #0 - process has been terminated

root@d391259bf577:/# ./killmenow Terminated root@d391259bf577:/#

GitHub repository:

alx-system_engineering-devops

Directory:

0x0A-configuration_management

File:

2-execute_a_command.pp
